Product Description:

The 63A 4-Pin Industrial Wall-Mount Socket is a heavy-duty, surface-mounted power outlet designed for 400V three-phase electrical systems with earth (3P+E)—where a neutral conductor is not needed. Engineered to meet IEC 60309 standards, this socket is ideal for safely powering motors, compressors, welding machines, and other industrial equipment.

With its IP44 splashproof rating, it offers reliable protection against dust and water spray, making it suitable for use in factories, workshops, generator panels, and construction environments. The socket features a flame-retardant thermoplastic housing and nickel-plated brass contacts, delivering dependable performance even in demanding conditions.

Key Features:

• Rated Current: 63 Amps

• Voltage: 400V AC

• Poles: 4 (3 Phase + Earth / 3P+E)

• Frequency: 50/60Hz

• Mounting Type: Wall-Mount (Surface installation)

• Design: Female socket with hinged protective cover

• Ingress Protection: IP44 – Splashproof

• Cable Entry: Rear or side knockouts for conduit/gland

• Connection Terminals: Screw-type

• Housing Material: Flame-retardant, high-impact thermoplastic

• Contact Material: Nickel-plated brass

• Color Code: Red (for 400V per IEC 60309)

• Operating Temperature: -25°C to +80°C

• Standard Compliance: IEC 60309-1 / IEC 60309-2

Applications:

• Industrial motor and pump connections

• Generator or switchboard output sockets

• Food and beverage processing facilities

• Agricultural and marine power setups

• Warehouse and heavy equipment installations

• Welding and HVAC systems

What’s Included:

• 1x 63A 4-Pin Wall-Mount Industrial Socket (Female, IP44)

• Mounting screws and seal

• Installation guide
