Product Description:

The 1000×800×250 mm Steel Electrical Enclosure is a robust and spacious solution designed to house and protect complex electrical systems in demanding environments. Made from high-quality cold-rolled steel and coated with a durable powder finish, this enclosure is ideal for industrial automation, power distribution, and commercial electrical setups.

Its IP65 rating ensures superior protection against dust, moisture, and accidental contact, making it suitable for both indoor and outdoor installations.

Key Features:

• External Dimensions: 1000 mm (H) × 800 mm (W) × 250 mm (D)

• Material: Cold-rolled mild steel, powder-coated

• Color: RAL 7035 Light Grey

• IP Rating: IP65 – Fully dustproof and water-resistant

• Door: Hinged single-door with a continuous gasket seal

• Locking System: Cam lock with two keys included

• Mounting Plate: Removable galvanized steel back panel for component installation

• Cable Entry: Bottom knockouts provided (customizable)

• Mounting Style: Wall-mounted with external brackets included

• Certifications: CE certified | Built to IEC 60529 standards

Applications:

• Electrical distribution panels

• Industrial automation and PLC housing

• Renewable energy control boxes

• HVAC and pump system control

• Machine control panels

• Process instrumentation systems

Specifications Table:
