Cable Gland Blanking Plug M12 × 1.5 (Sealing Plug)
GH₵1.50
GH₵2.00
Pickup currently not available
Detailed Description
A high-quality cable gland blanking plug for sealing unused cable entry points with M12 × 1.5 metric threads. Ideal for electrical enclosures, junction boxes, panels, or machinery where unused gland holes need to be closed off to prevent ingress of dust, moisture, or contaminants.
Key Features & Specifications
| Attribute | Specification / Notes |
|---|---|
| Thread | M12 × 1.5 (metric) |
| Type | Blanking / sealing plug for cable gland port |
| Material | (e.g. nickel-plated brass, or nylon / polyamide option) |
| External Diameter | ~14–16 mm typical (depending on design) productsforautomation.com+2RS Components+2 |
| IP Rating | Often IP68 for brass types (dust tight, continuous immersion) Camden Tools |
| Temperature / Environment | Depends on material; brass suitable for many environments; nylon version typically for general use CPC UK+1 |
| Use Case | Sealing off unused threaded holes, protecting enclosures from ingress, improving appearance, maintaining environmental rating, etc. |
Operational / Usage Notes
-
Install by threading it into the unused M12 gland hole; tighten sufficiently to compress seals (if present) but avoid over-torqueing.
-
Select the material (brass, nickel-plated brass, or nylon) based on environment (corrosion resistance, temperature, chemical exposure).
-
Ensure that the plug’s IP rating meets enclosure protection requirements if environmental sealing is needed.
