Cable Gland Blanking Plug M32 × 1.5 (Sealing Plug / Cap)
  • Cable Gland Blanking Plug M32 × 1.5 (Sealing Plug / Cap)
  • Cable Gland Blanking Plug M32 × 1.5 (Sealing Plug / Cap)
  • Cable Gland Blanking Plug M32 × 1.5 (Sealing Plug / Cap)
  • Cable Gland Blanking Plug M32 × 1.5 (Sealing Plug / Cap)
Cable Gland Blanking Plug M32 × 1.5 (Sealing Plug / Cap)

Cable Gland Blanking Plug M32 × 1.5 (Sealing Plug / Cap)

GH₵7.20 GH₵8.00

Detailed Description

A robust blanking or sealing plug for closing off unused M32 × 1.5 threaded cable gland holes. Designed to maintain enclosure integrity by preventing dust, moisture, or contaminants from entering through unused cable ports.

Key Specifications & Features

Feature Typical Value / Notes
Thread M32 × 1.5 metric
Type Blanking / sealing plug (male)
Material Options Nylon / polyamide (e.g. PA66), or nickel-plated brass
Operating Temp. For plastic EX-rated version: –50 °C to +95 °C
Protection / IP Rating Often rated IP66 for standard plugs (plastic EX version)   with good sealing, can approach IP68 depending on design
Dimensions & Weight In the Malux technical table, for M32 × 1.5, screw-in thread length (L1) ~ 36 mm, overall length (L2) ~ 35.5 mm, and plug weight ~ 27.6 g
Application / Use Cases Sealing unused cable entries in junction boxes, electrical enclosures, control panels, machinery; preserving ingress protection; future expansion capability

Usage & Installation Notes

  • Ensure the threaded opening or gland plate is clean, undamaged, and correctly sized to M32 × 1.5 before installation.

  • Insert and tighten the plug just enough to compress the sealing gasket / O-ring (if present) without over-torqueing (which could distort threads or the seal).

  • Choose material (plastic vs brass) depending on environment (e.g. chemical exposure, UV, mechanical stress).

  • Confirm that the plug’s environmental protection (IP rating) meets or exceeds that of the enclosure or assembly.
