Cable Gland Blanking Plug M16 × 1.5 (Sealing Cap / Plug)
GH₵2.00
GH₵2.50
Pickup currently not available
Detailed Description
A durable blanking (sealing) plug designed to seal off unused cable entry holes with M16 × 1.5 metric threads. Useful for securing electrical enclosures, junction boxes, control panels, or machinery against ingress of dust, moisture, or contaminants.
Key Specs & Features
| Feature | Detail / Typical Values |
|---|---|
| Thread | M16 × 1.5 metric |
| Type | Blanking / sealing plug / screw-in stopper |
| Materials | Options include nickel plated brass or nylon / polyamide (e.g. Woertz uses MS-Ni for brass) |
| Sealing / Protection | Many brass blanking plugs offer IP66 / IP68 levels of protection, depending on design and O-rings |
| Temperature / Operating Range | Typically suitable for –20 °C to +70 °C or more, depending on materials and seals |
| Dimensions & Torque | According to blanking plug spec tables, for M16×1.5: spanner width ~ 24 mm, screw-in length ~ 25 mm, recommended torque ~ 1.0 Nm (approx) |
| Weight | Approx ~ 9 g for typical blanking plug design for M16×1.5 (brass) |
| Use Cases | Sealing off unused gland holes; maintaining enclosure integrity; future expansion of wiring; avoiding ingress of dust and moisture |
Installation / Usage Notes
-
Ensure thread compatibility (M16 × 1.5) with the hole or gland plate.
-
When inserting the blanking plug, tighten until the seal compresses (if it has an O-ring) but avoid over-torque.
-
For environments requiring high ingress protection, choose designs rated IP66 / IP68 and ensure the plug’s sealing surfaces are clean and undamaged.
-
Consider material compatibility with the environment (e.g. brass for corrosion resistance, nylon for light weight / general indoor use).
